Battery Backup Hybrid Solar Inverter 5600W Single Phase 230V With Grid Feed Prevention for OEM Orders

Name: Battery Backup Hybrid Solar Inverter 5600W Single Phase 230V With Grid Feed Prevention for OEM Orders
Brand: Solarose
Price: 295 USD

Brand Name : Solarose

Model Number : inverter 5600W

Certification : UL; CE

Place of Origin : Guangdong,China

MOQ : 10

Price : $295

Packaging Details : one pc is in a carton

Rated Output Power : 5600W

Battery Voltage : 51.2VDC

AC Output Voltage : 230V ±5%, 50Hz

PV Input Voltage Range : 90V – 500VDC

Max PV Input Power : 6000W

Max Charging Current (AC + PV) : 100A

Grid Interactive Mode : Yes, with utility power blending

Anti-Backfeed Capability : Built-in for reverse current prevention

Contact Now

5600W Hybrid Solar Inverter Single Phase 230V With Battery Backup And Grid Feed Prevention

Product description:

This 5600W single-phase hybrid inverter is designed for residential and light commercial energy storage systems. It supports both on-grid and off-grid modes and allows battery charging from utility and solar simultaneously (up to 100A). With wide PV input range (90–500VDC) and anti-backflow function, it efficiently manages power usage while ensuring compliance with local grid standards. It integrates a pure sine wave inverter, MPPT solar charger, and battery management in one compact design, making it ideal for grid-tied hybrid applications.

Technical parameter

Rated Output Power	5600W
Battery Voltage	51.2VDC
AC Output	230V, 50Hz (Single Phase)
PV Input Voltage Range	90V – 500VDC
Max PV Power	6000W
Charging Current (Grid + PV)	Up to 100A
Anti-Reverse Feed	Yes, built-in anti-backfeed system
Operation Mode	Hybrid (On-grid + Off-grid Support)

Feature Advantages:

Grid and solar hybrid operation for flexible energy use
Pure sine wave output suitable for sensitive electronics
100A high-efficiency dual charging capability
Anti-reverse current feature protects against grid feedback
6000W PV input power supports larger solar arrays
Wide 90–500V DC input range optimizes PV performance
Integrated MPPT and battery management in one unit
Compact and user-friendly design for easy installation
